TIG Welding

What is TIG Welding

Tig welding, is an arc welding process that uses a non-consumable tungsten electrode to produce the weld.

The weld area and electrode are protected from oxidation or other atmospheric contamination by an inert shielding gas (argon or helium). A filler metal is normally used, though some welds, known as autogenous welds, or fusion welds.

When helium is used, this is known as heliarc welding. A constant-current welding power supply produces electrical energy, which is conducted across the arc through a column of highly ionized gas and metal vapors known as a plasma. Tig welding is most commonly used to weld thin sections of stainless steel and non-ferrous metals such as aluminum, magnesium, and copper alloys.

The process grants the operator greater control over the weld than competing processes such as shielded metal arc welding and gas metal arc welding, allowing for stronger, higher quality welds.

However, Tig Welding is comparatively more complex and difficult to master, and furthermore, it is significantly slower than most other welding techniques. A related process, plasma arc welding, uses a slightly different welding torch to create a more focused welding arc and as a result is often automated.

Parweld XTT 182 DV

180A DC TIG Inverter Dual Voltage

DC Output The dual voltage XTT 182DV has a DC output and is suitable for welding alloy, non alloy steels, stainless steel and titanium. TIG Mode - Materials up to 5mm can be welded with ease. MMA Mode - Electrodes up to 4.8mm can be used with ease. TIG Welding The XTT 182DV can be used for TIG welding and is suitable for welding steel and stainless steel using the HF start circuit. The latching trigger function improves operator comfort allowing the trigger to be released during long welds. Generator Friendly The XTT 182DV is able to cope with inputs which fluctuate by +/-15% and can be used with the majority of generators. The machine is housed in a metal case with integrated carry handle and shoulder strap. A carry case is available as an optional extra.

Key Features
- Dual voltage 110/230V
- Lightweight 7.8kg
- 180A @ 60% duty cycle
- Generator friendly
- Easy electrode re-striking with hot start (MMA)
- HF arc starting
- Adjustable post flow (TIG mode)
- Supplied with 3m earth lead
- Latching trigger option (TIG mode)
- Adjustable downslope (TIG mode)
- Connections 35-50mm dinse
- 3 Years return to base warranty + 3 years servicing plan
- Manufactured to IP23S, ISO/IEC 60974-1, ISO/IEC 60974-6 & RoHS Compliant
- 3m Input Cable, 3m Earth Lead, Gas Hose

Call Us Now

INVERTEC 220TPX

TIG welder combining a rugged industrial construction with excellent arc characteristics

Call Us Now

Parweld XTT250 DC P

The XTT 250 DC P can be used for TIG or MMA welding allowing the welding of a wide range of steels and alloys. DC output and power pulsing maximises productivity whilst reducing heat output. The majority of steels can be welded in DC mode quickly using the pulse power function, giving the flexibility of reducing heat input or increasing the welding speed and weld penetration at higher pulse frequencies. Materials up to 8mm can be TIG welded, and thicker using MMA.

Call Us Now

INVERTEC 300TPX

Advanced inverter technology for superior DC TIG performance. Industrial TIG welder for tough conditions.

Key Features
- Fully functional, user-friendly control panel layout with graph and numeric display makes it easy to set all welding parameters.
- Rugged construction: electrical safety (IP23S), potted PC boards and optimum airflow reduce contamination to extend the equipment's lifespan in the harshest environmental conditions.
- HF and Lift TIG ignition meeting all requirements.
- Perfect TIG HF starting with pre-settable starting mode.
- Complete TIG parameters setting: Pulse TIG with variable frequency that allows the welder to adjust the arc focus to suit the applications, 10 memory slots for personalized welding settings, TIG Spot welding.
- Water Coolers and Carts available

Call Us Now

Parweld XTT 212Di AC/DC Pulsed

The XTT 212Di single-phase AC/DC Pulsed TIG Inverter is capable of HF TIG, Lift TIG, and MMA welding. This dual voltage (110V/230V) compact and lightweight machine has a multi-language digital user interface, which rapidly gets you to the correct machine setting with minimal process knowledge, on site or in the workshop.

Advanced settings for each process can be accessed from the front panel. There is also a memory option that allows you to save and recall up to 6 welding jobs. The XTS 908 Unit Attachment allows for the option of water cooling the TIG Power Source Machine. Compatible with optional Foot Control device.

Call Us Now

Aspect 200

Leading technology in TIG AC/DC welding with a user friendly interface and innovative remote control system from the torch.

Call Us Now

Aspect 300

Aspect 300 is an industrial AC/DC TIG welding machine designed and manufactured using the latest inverter digital technology.

Key Features
- Advanced waveform technology for the best aluminium welding performance.
- Advanced TIG AC & DC Functions – Four wave shapes, Pulse, adjustable Balance and Offset, innovative and simple control panel, AC auto setting.
- Variable AC frequency (40-400 Hz) for the control of travel speed and penetration.
- Fully functional, user-friendly control panel layout with graph and a numeric display makes it easy to set all welding parameters.
- Cellulosic capability.
- Energy efficient 3 phase buck-boost circuit for energy saving

Call Us Now

Parweld XTT 353 P

350A AC/DC Pulse TIG Inverter 400V

AC/DC Output The XTT 353P AC/DC can be used in both AC and DC modes for TIG or MMA welding allowing the welding of virtually any metal. Square wave AC output and power pulsing maximises productivity whilst reducing heat output. The majority of steels can be welded in DC mode quickly using the pulse power function. The AC mode allows the welding of aluminium and magnesium alloys. The square wave output maximises adjustable frequency maximises the arc energy, offering high welding speeds when coupled with the power pulsing function. Generator Friendly The XTT 353P AC/DC is able to cope with inputs which fluctuate by +/-15% & can be used with the majority of generators.
