PLASMA CUTTING

What is Plasma Cutting?

Plasma cutting is a process that cuts through electrically conductive materials by means of an accelerated jet of hot plasma. Typical materials cut with a plasma torch include steel, stainless steel, aluminium, brass and copper, although other conductive metals may be cut as well. Plasma cutting is often used in fabrication shops, automotive repair and restoration, industrial construction, and salvage and scrapping operations. Due to the high speed and precision cuts combined with low cost, plasma cutting sees widespread use from large-scale industrial CNC applications down to small hobbyist shops.

TOMAHAWK 30K

Portable, flexible cutting power of up to 16 mm, powered from a standard 230V input supply, ideal for work on site.

Key Features
- Ultimate Portability – Internal air compressor enables operation in environments where external compressed air is not available.
- Continuous Output Control – Focus the arc for different material thickness
- Touch Start system – Reliable plasma arc initiation without high frequency
- Rapid Arc Restrike – Fast cutting through gaps, even expanded metal.
- Front Panel Purge Control – Makes it easy to set the air flow rate without initiating the plasma arc.
- Cool Operation, Long Consumable Life – New electrode and nozzle design save you money in the long run
- Added Safety – Our Parts-in-Place system detects correct installation of consumables and torch.
- Engine Drive Compatible – Select a Lincoln Electric Outback® or Vantage® to power your Tomahawk® in remote locations

Call Us Now

XTP 40 Dual Voltage Inverter Plasma Cutter

Inverter Plasma Cutter c/w XT4000 Torch 110/230V

Variable Output The variable output of the XTP 40 makes it ideal for cutting metals up to 12mm thick where the output power can be fine tuned to minimise dross on the cut edges. The pilot arc automatically re-ignites enabling easy cutting of mesh or perforated materials. Non HF ignition minimises the risk of interference with electronic systems. Generator Friendly The XTP 40 is able to cope with inputs which fluctuate by +/-15% & can be used with the majority of generators. The machine is housed in a metal case with a carry handle & shoulder strap.

Key Features
- Lightweight 12.6kg
- 40A @ 40% duty cycle
- Generator friendly
- Smart switching dual voltage 110-230V
- Ideal for mesh cutting
- 12mm production cut
- 20mm severance cut
- Supplied with XT4000 plasma torch x 6m & 3m earth cable
- Auto over voltage & over current protection
- Includes built in air pressure regulator
- 3 Years return to base warranty + 3 years servicing plan
- Manufactured to IP23S, ISO/IEC 60974-1, ISO/IEC 60974-6 & RoHS Compliant
- 3m Input Cable, 3m Earth Lead, Gas Hose

Call Us Now

TOMAHAWK 45

Portable, flexible cutting power of up to 20 mm, powered from a standard 120 and 230V input supply, ideal for work on site.

Key Features
- TFT 2,8” screen – For an easier and user friendly user interface
- Continuous Output Control – Focus the arc for different material thickness.
- Touch Start system – Reliable plasma arc initiation without high frequency
- Rapid Arc Restrike – Fast cutting through gaps, even expanded metal
- Front Panel Purge Control – Makes it easy to set the air flow rate without initiating the plasma arc.
- Gouging and Grid modes ( adjustable grid’s time )
- Cool Operation, Long Consumable Life – New electrode and nozzle design save you money in the long run.
- Added Safety – Our Parts-in-Place system detects correct installation of consumables and torch.
- Lightweight and Portable – Easily carried by one person.
- Engine Drive Compatible – Select a Lincoln Electric Outback® or Vantage® to power your Tomahawk® in remote locations.

Call Us Now

XTP63 Inverter Plasma Cutter

Inverter Plasma Cutter c/w XT4000 Torch 400V

Variable Output The variable output of the XTP 63 makes it ideal for cutting metals up to 20mm thick. Infinite power control allows the output to be tuned to minimise dross on the cut edges. The pilot arc automatically re-ignites enabling easy cutting of mesh or perforated materials. Non HF ignition minimises the risk of interference with electronic systems. Generator Friendly The XTP 63 is able to cope with inputs which fluctuate by +/-15% & can be used with the majority of generators. The machine is housed in a metal case with carry handle.

Call Us Now

XTP103 Inverter Plasma Cutter

Inverter Plasma Cutter c/w A141 Torch 400V

Variable Output The variable output of the XTP 103 makes it ideal for cutting metals up to 30mm thick. Infinite power control allows the output to be tuned to minimise dross on the cut edges. The pilot arc automatically re-ignites enabling easy cutting of mesh or perforated materials. Non HF ignition option minimises the risk of interference with electronic systems. Generator Friendly The XTP 103 is able to cope with inputs which fluctuate by +/-15% & can be used with the majority of generators. The machine is housed in a metal case with carry handles.

Key Features
- 400V 3 phase
- 100A @ 100% duty cycle
- Generator friendly
- Ideal for mesh cutting
- 30mm production cut
- 50mm severance cut
- CNC interface & HF start
- Supplied with A141 plasma torch 6m & 3m earth cable
- Auto over voltage & over current protection
- Includes built in air pressure regulator & pressure gauge
- Optional XT4000 torch for non HF operation up to 600A
- 3 Years return to base warranty + 3 years servicing plan
- Manufactured to IP23S, ISO/IEC 60974-1, ISO/IEC 60974-6 & RoHS Compliant
- 3m Input Cable, 3m Earth Lead, Gas Hose

Call Us Now

TOMAHAWK 1025

High performance plasma cutting machine: built to handle harsh environmental conditions, suitable for on-site operations with a generator or within a workshop environment.

Call Us Now

TOMAHAWK 1038

High performance plasma cutting machine: built to handle harsh environmental conditions, suitable for on-site operations with a generator or within a workshop environment.
